WEIGHT 89287 lb*
POWER 260 hp
TORQUE 24339 lb·ft*
EXTRACTION 38217 lbf*
DMS N/A
* VARIES BASED ON CONFIGURATION
The SM-28 is a new multipurpose rig from Soilmec built for quick assembly and transport. It supports a number of applications and attachments, such as top hammer, CFA (w/ clamp & guide), single- and double-rotaries, jet grouting, and rod carousel, with increased flexibility via mast tilt to 18˚. Like all Soilmec rigs, the SM-28 is self-assembling, versatile, and easily transportable.
Standard Equipment:
- Drill mast 16000mm stroke
- Clamp and breaker 60-430mm
- Pneumatic inline DTH lubricator
- Kinematic mechanism
- Rotary cradle with side shifting
- Service winch
- Load-sensing hydraulic system
- Air/water system & line lubricator for DTH
- Radio remote control
- On-board safety controls
- Telescopic zoom on base body
Optional equipment: reference data sheet.
